HD4K18GB-FO-20M-MMLC: Directional Hybrid Cable For Extending A 4K Ultra-HD 60Hz 4:4:4 HDMI Display

HD4K18GB-FO-20M-MMLC: Directional hybrid cable for extending a 4K Ultra-HD 60Hz 4:4:4 HDMI display

with fiber optic and copper cores, immune to signal noise with low RFI/EMI for sensitive applications

---

• HDCP 2.2
• No power supply required

XTENDEX^® low-cost 4K HDMI active optical cable locates an Ultra-HD 4Kx2K 60Hz 4:4:4 HDMI display up to 65.6 feet from a video source.

Using optical fiber, the cable provides high reliability HDMI signal transmission with zero signal loss in high noise environments.

Ideal solution for many applications, including:
• Digital Signage
• Medical Imaging Equipment
• Airplane On-board Video System
• Home Theater
• TV Broadcast Station
• Conference Room Video Equipment

Supported HDMI Features
• HDMI 2.0
• Up to 16-bit Color and 48-bit Deep Color
• YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0, and RGB
• Dolby TrueHD, DTS-HD Master Audio, Dolby Digital, DTS Dolby, and LPCM 7.1
• Bandwidth up to 18Gbps
• Supports ARC, HDR, and CEC
• 3D
• Lip Sync

Features and Benefits
• High speed and long distance transmission by optical system
• Hybrid cable containing both fiber optic and copper cores
• Supports Ultra-HD 4Kx2K resolutions to 3840×2160 and 4096×2160 @ 60Hz YUV 4:4:4, and HDTV resolutions to 1080p @144Hz
• No loss of signal – delivering crystal clear digital images instantly
• No external power required
• HDCP 2.2 compliant
• Optical fibers immune to signal noise
• Low RFI/EMI for sensitive applications
• Supports Plug-n-Play specification
• EDID learning for the support of any HDMI display device
• Thin and ultra-lightweight construction

Note: These cables are directional – see labeled connector ends
